SIMPLIS Technologies Announces the Release of SIMetrix/SIMPLIS 8.3

SIMPLIS Technologies is pleased to announce that we have released version 8.3 of SIMetrix/SIMPLIS.  Below is the breakdown of the major changes.

New Features for Both SIMetrix and SIMPLIS

Curve Colour-label Editor

A simple dialog to speed editing of curve colours and labels

colour label editor
Simulator: SIMetrix and SIMPLIS
Required Version: Classic, Pro, or Elite

Other Improvements

  • Schematic: Mouse panning using right button
  • Schematic: Auto pan during edit operations
  • Waveform viewer: Replot previously closed waveforms
generic schematic image
Simulator: SIMetrix and SIMPLIS
Required Version: Classic, Pro, or Elite

New Features for the SIMPLIS Simulator

4-Quadrant Multipliers

Two four-quadrant multipliers where the inputs and outputs can swing above and below the ground reference, providing true four-quadrant multiplication. Versions with and without output limiting are included.

From the Part Selector, select Analog Functions > Multiplier / Divider > 4-Quadrant to place.

More information

4-quadrant multipliers
Simulator: SIMPLIS
Required Version: Classic, Pro, or Elite


Create a SIMPLIS MOSFET model by digitizing capacitance, transconductance, and body diode behavior datasheet curves. Or, start with a SPICE model and fine tune the extracted SIMPLIS model.

More information

custom mosfet dialog

Simulator: SIMPLIS
Required Version: Classic*, Pro, or Elite
*Classic version does not support digitizing curve feature.

New Features for the SIMetrix Simulator

Sensitivity and Worst-case Analyses

Sensitivity and true Worst-case analyses are now available for SIMetrix simulations. The analysis modes are built into the simulator core and can be specified at the netlist level.

More information

sensitivity dialog
Simulator: SIMetrix
Required Version: Pro, or Elite

Verilog-A Features

Further work with the Verilog-A compiler provides three new features:

  • Z-transform Functions (See picture)
  • Indirect Branch Assignments
  • Full version 2.4 implementation of $table_model including cubic spline interpolation

More information

critically damped pulse graph
Simulator: SIMetrix
Required Version: Pro, or Elite

See the full list in the Change Log.

How to get version 8.30

For those interested in evaluating SIMetrix/SIMPLIS 8.30, please head to the Evaluation page and follow the directions to obtain a trial license.

For those who are up to date on their maintenance but do not possess the credentials for downloading the new version, please contact us at
